Description
For chair:
Seat Width: | 14″ / 16”/ 18”/ 20”/ 22” |
Seat Depth: | 16” |
Front Seat Height: | 20” |
Rear Seat Height: | 19.5” |
Back Height: | 17.5” |
Rear Wheel: | 12 ½” x 2 ¼” |
Front Wheel: | 8”x 2” |
Overall Width: | 23″ / 25”/ 27”/ 29”/ 31” |
Overall Depth: | 42” |
Overall Height: | 38 ¼” |
Seat to Armrest Height: | 9.5”- 13” |
Weight: | 38.9 kg (without battery) 66 kg (with battery) |
Weight Capacity: | 136 kg (14″/16”/18”/20”) 181 kg (22”) |
Country of Origin: | China |
Warranty: | 1 year on frame only 6 months for battery * Against manufacturing defects |
For Battery:
Battery Size: | 12V,35AH x 2 |
Battery Weight: | 25.4 kg (for two batteries) |
Range: | 24 km (14″/16”/18”/20”) 16 km (22”) |
Charger: | 4A charger |
Motor: | 2 x 320W, 4600 RPM 32:1 |
Brake: | Electromagnetic brake |
Brake Application: | 140cm |
Controller: | PG 60A |
Climbing angle: | 8° |
Maximum speed: | 8 km/h (Forward) 4 km/h (Backward) |
Turning Radius: | 29″ / 30″ / 32″ / 33″ / 35″ |
Controller: | P&G VSI 50A |
Charger: | HP DC 24V, 4A |
Charging Time: | 8 hrs |
Cruising Range: | 18 km |
Packing size: | Powerchair: 77 x 36 x 94 cm Battery (x2): 34 x 23 x 24.5 cm |
